ltems:LF | 15212/24/48 | 20212/24/48 | 30224/48 | 40224/48 | 50248 | 60248 | 80248 | 10348 | 12348 |
Rated Power | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | 8000W | 10KW | 12KW |
Phase Type | Single phase L-N:Split phase can be customized L1-L2,L1-N,L2-N |
Standard Battery Voltage | 12/24/48VDC | 24/48VDC | 48VDC |
Battery Type | Lead-acid/Gel Battery /Lithium Batteries / Custom battery |
Rated Input Voltage | 110VAC/120VAC/220VAC /230VAC/240VAC |
AC Input Voltage Range | 85VAC-138VAC(110VAC)/95VAC-148VAC(120VAC)/170VAC-275VAC(220VAC)/180VAC-285VAC (230VAC)/190VAC-295VAC(240VAC) |
AC lnput Frequency Range | 45Hz-55Hz(50Hz),55Hz-65Hz(60Hz) |
Output Wave/Conversion Efficiency | Pure Sine Wwave/ >85% |
Ac output Voltage / FrequencyRange(INV mode) |
| 110VAC土2%/120VAC土2%/220VAC±2%/230VAC土2%/240VAC土2%,50/60Hz±1% |
Rated Current | 30A-60A | 60A-100A | 100A |
PV Array Max Power | 12V(420W)/24V(840W)/48V(1680W)
| 12V(840W)/24V(1680W)/48V(3360W)
| 5600W |
| Max PV input Voltage(Voc)(At The Lowest Temperature) | 12V/24V ststem:120VDC;48V ststem:180VDC |
MPPT TrackingVoltage Range | 12V ststem(15V-80V)/24V ststem(30V-100V)/48V ststem(60V-140V) |
Protection | Battery undervoltage protection/Battery overvoltage protection/Overload power protection/ Inverter output short circuit protection/Temperature protection |
Display | LCD |
Communication lnterfaces | RS485/RS232,APP(WIFl monitoring or GPRS monitoring)Optional |
Product Size(L*W*Hmm) | 470*300*148
| 530*335*158
| 684*430*250 |
Packing Size(L*W*Hmm) | 545*385*223
| 605*420*233
| 705*485*315 |
N.W.(kg) | 13.5 | 18 | 20 | 22 | 26 | 24 | 45 | 55 | 58 |
G.W.(kg) | 15 | 19.5 | 21.5 | 24 | 28 | 26 | 52 | 62 | 65 |
