Items | Parameters | Remarks |
| Rated Capacity | Nominal Capacity | 80Ah | Charging @ 25℃，20A
/ Discharging @ 20A |
| Min. Capacity | 79Ah |
| Nominal Voltage | 51.2V |
|
| Nominal Energ | 4096Wh |
|
| Cycle Life
（0.2C charge&0.5C
discharge） | ≥3000 | 25℃@80%DOD，SOH＞70% |
| Self-Discharge Rate（30 Days） | ≤5% | 25±2℃ |
| Discharge Rate | ≥100% | 0.2C |
| ≥96% | 0.5C |
| Charge Voltage | 58.4V |
|
| Discharge Cut-off Voltage | 40V |
| Internal Resistance | ≤30mΩ |
|
| Standard Charging | 20A |
|
| Standard Discharging | 30A |
|
| Max. Charing Current | 40A |
|
| Max. Discharging Current | 50A |
|
| IP Level | IP54 |
|
| In Series or Parallel | Not Supported |
|
| Operating Temperature Range | Charging：0～55℃ |
|
| Discharging：-10～60℃ |
| Optimum Storage Temperature | 10-35℃ | Relative humidity: 60±25%R.H |
| Size | 470mm*275mm*213mm |
|
| Net Weight | ＜40kg |
|
| Energy Density | ≥102.4Wh/kg |
|
| SOC when delivery | 50%±5% |
|
|
| Voltage when delivery | 52.5V±0.5V |
|
| Connector Anderson | Anderson 50A |
|
| Package | Carton |
|
| Wooden Box |
